In keeping with its comprehensive approach to plant components, Tetra Pak supplies an extensive range of measuring instruments. This is a specialist area that you can discuss in depth with us to ensure that we satisfy your process monitoring needs. Selected components from leading manufacturers
Product detail
| Product code | Endress + Hauser: Analysis transmitters, PH, Turbidity, Nitrate, Chlorine |
| Applications | For processes in treatment of industrial water and wastewater |
Liquiline CM44x series
Application: The Liquiline CM44x series are a serie of transmitters for the memosens technology that are used on this section of the catalogue. Both rack mounted and field mounted (with display) versions.
Benefits
- Clever simplicity - One controller for all parameters and applications - Intuitive user interface - Automatic sensor recognition - Hot plug & play with pre-calibrated Memosens sensors.
- Highest flexibility - Universal modules for all parameters minimize spare part stock and allow for easy 1-click extension to up to 8 channels at any time.
- Simple and safe commissioning - Convenient setup multiplication to other devices with SD-Card saves time and minimizes effort.
- Process control and safety - Integrated web server that allows the operator to remotely view diagnostic data, perform configurations, or access device parameters in any web browser - even via Smartphone.
PH CPF81D
Application: Orbipac CPF81D is the robust pH sensor for processes in treatment of industrial water and wastewater
Benefits
- Suitable for flow and immersion installation
- Long time stable - Second electrolyte bridge for better protection against electrode poisoning ions such as S2- or CN- - Robust polymer housing protects against mechanical damage
- Optional flat membrane suitable for high flow rates and fibrous media
- Maximum process safety through non-contact inductive signal transmission
PH CPS11D
Application: The CPC11D is a glass Ph sensor for Water treatment in Drinking water, cooling water and well water
Benefits
- Maximum process safety through non-contact, inductive signal transmission
- Enables predictive maintenance due to storage of sensor and process-specific data
- Reduced operating costs thanks to minimized process downtime and extended sensor lifetime
PH OUSAF11
Application: OUSAF11 is a glass-free sensor for the inline detection of changing phases and suspended solids
Benefits
- Highest safety for your products thanks to glass-free, hygienic design
- Cost savings and reduced product loss thanks to fast interphase detection
- Low-maintenance sensor with long service life and stable operation
- Flexible installation - Sensor features insertion (with Triclamp and Varivent connection) - Immersion (with holder and assembly system Flexdip CYA112 and CYH112)
- Robust sensor resists aggressive chemicals and fouling
- Suitable for cleaning-in-place (CIP) and sterilization-in-place (SIP)
- FDA and 3-A approval
Technical specifications
| Product code | Endress + Hauser: Analysis transmitters, PH, Turbidity, Nitrate, Chlorine |
| Applications | For processes in treatment of industrial water and wastewater |
Chlorine - CCS142D
Application: Chloromax CCS142D is the digital, free chlorine sensor for all kinds of water
Benefits
- Long calibration and maintenance intervals
- Easy membrane replacement thanks to prefabricated membrane cap
- Measured values are not affected by conductivity fluctuation
- Sensor can be installed in flow cell CCA250 or in immersion assemblies. Measurement virtually independent of the flow at flow velocities above 30 l/h or ~8 gal/h (CCA250) or above 15 cm/s or ~0.5 ft/s (immersion)
- Maximum process safety through no-contact inductive signal transmission
Nitrate - Viomax - CAS51D
Application: Viomax CAS51D measures nitrate or SAC in drinking water, process water and wastewater applications as well as the utilities sector. Organic load or nitrate in inlet and outlet Determination of CODeq or TOCeq Monitoring, control and optimization of treatment processes Nitrate monitoring in the aeration basin and denitrification stage
Benefits
- Cost-effective - Easy, chemical-free handling is safe, environmentally friendly and saves on operational expenditure
- Extremely fast response time - Measured value processing in the sensor provides reliable real-time process information
- Fast and easy commissioning - Sensor comes precalibrated and preconfigured ex factory
- Perfect adaption to open basins - Fast and flexible sensor positioning with Flexdip CYH112 holder and CYA112 assembly system
Turbidity - ITM-51- Anderson
Application: Preferred turbidity meter for detection of phase separation like water/milk phase but also for products like cream and whey
Benefits
- Compact front flush sensor
- Temp range -10…130 °C (Up to 140 °C max. 120 min for CIP)
- High reproducibility: ≤ 1 % of full scale
- Selectable output value (%TU, NTU, EBC)
- Measurement range: 200…300.000 NTU equivalent
